Simply45® the industry-leading brand for RJ45 modular plug innovation and performance solutions is proud to introduce our ProSeries Pass-Through RJ45 product line. The Simply45® ProSeries have the most innovative and ground-breaking improvements to RJ45 design and performance since the introduction of the original pass-through RJ45.

The Simply45® ProSeries Pass-Through RJ45 modular plugs are specially designed to provide greater electrical conductivity, improved cross talk performance, and the best PoE/PoH performance of any pass-through RJ45; all critical to supporting today’s LAN cable applications. Our ProSeries Pass-Through RJ45 is available for both unshielded and shielded LAN cable terminations.

Simply45® ProSeries RJ45 Pass-Through Connectors

S45-1755P - ProSeries 10G Shielded External Ground-Pass-Through RJ45 with Cap45® & Bar45®​

Simply45® ProSeries Pass-Through RJ45 Mod Plug- Shielded External Ground for 23AWG Solid, Conductor Type(s): Solid and Stranded, FPE Insulated 10G STP LAN Cables (Cat7a/7/6a) & 23AWG Solid, PE Insulated Cat6/6a STP, Hi/Lo Stagger, Wire Conductors 1.15mm-1.35mm/0.045″-0.053″, 2pc Plug with CAP45®, Bar45® Load Bar, Max Cable OD 8.0mm (0.315″), UL94 V0 Commercial Rated, Yellow Tint – 50pcs/Plastic Jar

PATENT: 10,811,831 B1

S45-1750P - ProSeries Cat6/6a STP Shielded External Ground - Pass-Through RJ45 with Cap45® & Bar45®

Simply45® ProSeries Pass-Through RJ45 Mod Plug- Shielded External Ground for 23AWG Solid, Conductor Type(s): Solid and Stranded, PE Insulated Cat6/6a STP, Hi/Lo Stagger, Wire Conductors 1.10mm – 1.20mm (0.043” – 0.047”), 2pc Plug with CAP45®, Bar45® Load Bar, Max Cable OD 8.0mm (0.315″), UL94 V0 Commercial Rated, Red Tint – 50pcs/Plastic Jar

Simply45® the industry-leading brand for RJ45 modular plug innovation and performance solutions introduces our ProSeries Shielded with External Ground Pass-Through RJ45 Modular Plug, S45-1750P. The uniquely designed and patented Simply45® ProSeries S45-1750P simplifies and improves the terminated plug performance for shielded Cat6/6a LAN cables. The Simply45® ProSeries S45-1750P Pass-Through RJ45 modular plugs are by far the highest performing, easiest to use, and most cost-effective way to professionally terminate Cat6 Shielded STP and Cat6a F/UTP LAN cables.

S45-1700P - ProSeries Cat6/6a Unshielded - Pass-Through RJ45 with Cap45®​

Simply45® ProSeries Unshielded Pass-Through RJ45 Modular Plugs with Cap45® for 23AWG Solid (Cat6/6a UTP), Conductor Type(s): Solid and Stranded, Hi/Lo Stagger, Wire Conductors 1.05mm-1.2mm/0.041″-0,047″, Max Cable OD 7.4mm/0.291″, UL94 V0 Commercial Rated, Red Tint- 100pcs/Plastic Jar

PATENT: 10,811,831 B1

Simply45® RJ45 Pass-Through Connectors

S45-1600 - Cat6 Unshielded - Pass-Through RJ45​

Simply45® Unshielded Pass-Through RJ45 Modular Plugs for 23AWG Solid (Cat6 UTP), 26-24AWG Stranded (Cat5e/6 UTP Stranded), Straight Insert, Wire Conductors 0.95mm-1.05mm/0.037″-0.041″, Max Cable OD 7.0mm (0.276″), UL94 V0 Commercial Rated, Green Tint – 100pcs/Plastic Jar. Previous Part No: SIMPLY45-CAT6

S45-1500 - Cat5e Unshielded - Pass-Through RJ45​

Simply45® Unshielded Pass-Through RJ45 Modular Plugs for 24AWG Solid (Cat5e UTP), 28-26AWG Stranded (Cat5e/6 Stranded), Wire Conductors 0.95 – 1.05mm/ 0.037″ – 0.041″, Max Cable OD 6.5mm (0.255″), UL94 V0 Commercial Rated, Blue Tint – 100pcs/Jar. Previous Part No: SIMPLY45-CAT5E

Simply45® Standard RJ45 Connectors

S45-1100 - Cat6 Unshielded - Standard WE/SS RJ45 with Bar45®

Simply45® Unshielded Standard WE/SS (8P8C) RJ45 Mod Plugs with Bar45® Load Bar for Cat6/6a UTP; Conductor Type(s): Solid and Stranded, 23AWG Solid PE Insulated, Wire Conductors 1.05-1.17mm/0.041″-0.046″, Max Cable OD 7.4mm (0.291″), Commercial Rated UL94V0, Green Tint- 100pcs/Jar

Simply45® Tools and Accessories

S45-C100 - Simply45® RJ45 Crimp Tool - Pass-Through Unshielded & Internal Ground Shielded

Simply45® Pass-Through RJ45 Crimp Tool for UTP & Internal Ground Shielded Pass Through RJ45 Mod Plugs, Built-In Stripper/Cutter – 1Ea/Blister. Previous Part No: SIMPLY45-CRIMPER.

Ratcheted for Full Compression Cycle. A ratcheted crimp tool requires the installer to complete the full crimping cycle. While some RJ45 brands are eliminating this feature with their crimp tools, Simply45® knows that a ratcheted crimp tool is critical to ensuring that the RJ45 pins are properly seated onto the wire conductors and the pass-through wires are properly trimmed.  A ratcheted crimp tool prevents incomplete plug termination.

S45-S01BL - Adjustable LAN Cable Stripper for Shielded & Unshielded Cat7a/6a/6/5e - Blue​

Simply45® Professional Adjustable LAN Cable Stripper & Cutter – For Shielded & Unshielded Cat7a/6a/6/5e UTP/STP. Includes Wire Straightener Comb- Blue- 1Ea/Blister. Previous Part Number: SIMPLY45-STRIP-BL

Turning Knob for Precise Stripping Depth. It is very easy to adjust the stripping depth of the S45-S01BL Adjustable LAN Cable Stripper. Simply turn the knob counterclockwise to raise the trimming blade or turn the knob clockwise to lower the trimming blade to the cable jacket. You will notice that the knob is a little stiff. This is important as the tool holds its position in the same place so that you can complete multiple cable strips without having to adjust the tool each time.

S45-S01YL - Adjustable LAN Cable Stripper for Shielded & Unshielded Cat7a/6a/6/5e - Yellow​

Simply45® Professional Adjustable LAN Cable Stripper & Cutter – For Shielded & Unshielded Cat7a/6a/6/5e UTP/STP. Includes Wire Straightener Comb- Yellow- 1Ea/Blister. Previous Part Number: SIMPLY45-STRIP-YL

Turning Knob for Precise Stripping Depth. It is very easy to adjust the stripping depth of the S45-S01YL Adjustable LAN Cable Stripper. Simply turn the knob counterclockwise to raise the trimming blade or turn the knob clockwise to lower the trimming blade to the cable jacket. You will notice that the knob is a little stiff. This is important as the tool holds its position in the same place so that you can complete multiple cable strips without having to adjust the tool each time.

S45-801 - Premium 5" Flush Cutter Tool​

Simply45® 5″ Premium Flush Cutter Tool, Angled Jaw for Precision, Cushioned Grip, Wire Up To 18AWG – 1Ea/Blister

The Simply45® 5” Premium Flush Cutter Tool is a must-have in every installer’s tool kit.  This is not some cheap made Chinese tool. This is a professional premium quality, Flush Cutter. The S45-801 is ideal for trimming LAN cable wire conductors, precise trimming for load bars, jacks and more. It can be used with copper wires up to 18AWG (1mm).

S45-B003 - Strain Reliefs for Simply45® Shielded External Ground for Pass-Through & Standard RJ45

The Simply45® S45-B003 is an 8.5mm (0.33”) snagless strain relief for use with larger diameter shielded LAN cables. The S45-B003 is recommended for all Simply45® brand shielded with external ground RJ45 modular plugs. These 8.5mm strain reliefs protect the RJ45 modular plug and extend the useful life of the termination. Simply45® recommends that strain reliefs or boots should be used with all RJ45 terminations.

For Large Diameter LAN Cables. The Simply45® S45-B003 is designed to work with most large diameter LAN cables. It can work with cable diameters up to 8.5mm (0.33”). We recommend this strain relief/boot for all Shielded with External Ground RJ45 modular plugs. You can also use these strain reliefs with other unshielded large-diameter LAN cables such as Cat6 Shielded and Cat6 Shielded Direct Burial.

S45-B002 - Integrated Strain Reliefs for Simpy45® Unshielded Pass-Through & Standard RJ45 - Cat6/Cat6a



Simply45® Integrated Snagless Strain Reliefs for Simply45® Brand UTP & Internal Ground STP Pass-Through & Standard RJ45 Mod Plugs, Commercial Rated UL94 V0. Not for Cat5e UTP (See part: S45-B001)- Clear- 100 pcs/Resealable Bag. Previous Part Number: SIMPLY45-BOOT-CAT6



The Simply45® S45-B002 – Integrated Snagless Strain Reliefs lock into the RJ45 modular plug so that both the plug and strain relief can be permanently attached to the Simply45® RJ45 modular plug during the crimping cycle.

The Simply45® S45-B002 strain reliefs extend the useful life of the RJ45 modular plug termination and should be used with all terminations. It is also Fast and Easy to Use.

NOTE: The S45-B002 is designed to work with the following Simply45® part numbers: S45-1550, S45-1600/1601; S45-1700/1700P; S45-1100. For Cat5e Unshielded RJ45 modular plugs S45-1500/1501; S45-1000, please use our S45-B001 strain reliefs.

Simply45® S45-B002 Integrated Snagless Strain Reliefs for Cat6/6a and Cat5e Shielded with Internal Ground Features:
